Scope of application:
1. Can be used in zone 1 and 2 dangerous places.
2. Can be used in IIA、IIB、IIC，temperature classification from T1 to T3 in explosion gas environment.
3. Can be used in zone 20、21、22；flammable dust atmosphere.
Model implication:

Explosion-proof Flood Light
Features：
Aluminum alloy shell，high voltage static plastic sprayed surface.
Die-casting shape, compact structure and fine appearance.
A heat sink design on shell, Good heat dissipation effect.
It can be equipped with the mercury lamp、incandescent lamp、mercury lamp、high pressure sodium lamp、metal halide lamp.
Steel pipe or cable wiring.
Conform to GB3836－2000、IEC60079、GB12476.1－2000、IEC61241 standards.
Main technical parameters:
Explosion proof mark
|
IP rating
|
Inlet thread
|
Cable external diameter(mm)
|
Exd II BT3
Exd II CT3
DIPA20TA, T3
|
IP55
|
G3/4
|
Φ8-Φ13
|
Supplied with lamps:
Lamp type
|
Rated voltage(V)
|
Rated power(W)
|
Lamp holder
|
Shell type
|
Incandescent lamp
|
AC220
|
300
|
E40
|
I
II
III
|
500
|
Self-ballasted mercury vapor lamp （ML gas discharge lamp）
|
250
|
E40
|
450
|
Auxiliary ballast mercury lamp（HPL gas discharge lamp）
|
175、250
|
E40
|
400
|
High pressure sodium lamp（HPS gas discharge lamp）
|
150、250
|
E40
|
400
|
Metal halide lamp（MH gas discharge lamp）
|
175、250
|
E40
|
400
|
Outline and installation dimensions:


|
