The scope of application:
It can be used safety and reliably in the place with explosive zir mixture, wuth explosive material IIA, IIb.The temperature group is T1-T4 in canbin and outdoor place.
Products characteristic:
1.The shell is made of good quality brass foundry, toughened glass lamp-shade, with brass guard.
2.The gland has two kind, one is tube screw type, screw is G3/4, another one is bulge-type.
Authentication:
Approved by CCS.
Technical prameter:
Type
|
CFD2
|
CFD3
|
CFD3-1
|
Explosion-proof mark
|
ExdII BT3
|
Exd II BT4
|
Exd II CT4
|
Illuminant
|
Incandescent lamp
|
Lamp holder
|
E27
|
Protection class
|
IP55
|
IP55
|
IP56
|
Cable outside diameter
|
Diameter11-diameter13
|
Material
|
Brass
|
Power
|
220W
|
25W
|
40W/60W/100W
|
25W
|
40W/60W
|
40W/60W/100W
|
Voltage
|
220V
|
24V
|
220V/110V
|
24V
|
110V
|
220V
|
Weight
|
19Kg
|
13.5Kg
|
13.5Kg
|
8.5Kg
|
8.5Kg
|
8.5Kg
|
|
