The scope of application:
Applied to the illumination in 1-2 zone dangerous places of hidric gas and zir admixture, ethyne and zir admixture and other flammable gas admixture.
Products characteristic:
1.The body is made of good quality brass foundry, toughened glass lamp-shade, with brass guard.
2.The gland has two kinds, one is tube screw type, screw is G3/4. Another one is bulge-type.
Authentication:
Approved by CCS.
Technical parameter:
Type
|
CFD4a
|
CFD4b
|
CFD4c
|
Voltage
|
24V-220V
|
24V-220V
|
220V
|
Power
|
60W
|
25W
|
100W
|
Explosionproof mark
|
Exd II CT4
|
Exd II CT6
|
Exd II CT3
|
Illuminant
|
Incandescent lamp
|
Lamp holder
|
E27
|
Protection class
|
IP66
|
Cable outside diameter
|
Diameter 11-diameter13
|
Material
|
Brass
|
Weight
|
13Kg
|
|
