The scope of application:
Applied o the explosive gas zone 1 and zone 2 with the temperature group T1-T4, also suitable for remote illumination.
Products characteristic:
Good quality aluminium shell , brass guard and toughened glass, The light body can rotate 350° degree horizontally and 45°degrees pitching.
Authentication:
Approved by CCS.
Technical parameter:
Voltage
|
220v/50Hz,220V/60Hz,
|
Power
|
300W
|
400W
|
450W
|
Illuminant
|
Incandescent lamp
|
High pressure mercury light
|
Self ballast mercury lamp
|
Explosionproof mark
|
Exd II B T3
|
Lamp holder
|
E40
|
Protection class
|
IP56
|
Material
|
Aluminium
|
Cable outside diameter
|
Diameter 12-diameter 14.5
|
Weight
|
10Kg
|
Annex
|
|
Ballast
|
|
|
