Material
Body material
|
304/321/316/304L/316L Stainless steel
|
Glass material
|
Tempered glass,high borosilicate glass,quartz glass
|
Sealing gasket material
|
Silicone Polyethylene Tetrafluoroethylene,High temperature graphite
|
Working pressure
|
0-4.0MPa,0-2.5MPa
|
Working temperature
|
Tempered glass:≤200℃,high borosilicate glass:≤450℃,
quartz glass:≤600℃
|
Flange standard
|
HG20592-97PN1.0,GB,SH,HGI,JB,ANSI,JIS
|
Dimension
G
|
DN
|
PN 0.25Mpa
|
PN 0.6Mpa
|
Dimension
|
Glass
|
Dimension
|
Glass
|
H
|
L
|
Diameter
|
Thickness
|
H
|
L
|
Diameter
|
Thickness
|
1
|
25
|
200
|
181
|
65
|
10
|
200
|
189
|
65
|
10
|
5/4
|
32
|
260
|
226
|
95
|
15
|
260
|
234
|
95
|
15
|
3/2
|
40
|
260
|
226
|
95
|
15
|
260
|
234
|
95
|
15
|
2
|
50
|
320
|
226
|
140
|
20
|
320
|
278
|
140
|
20
|
5/2
|
65
|
320
|
226
|
140
|
20
|
320
|
278
|
140
|
20
|
3
|
80
|
360
|
300
|
165
|
20
|
360
|
308
|
165
|
20
|
4
|
100
|
360
|
300
|
165
|
20
|
360
|
308
|
165
|
20
|
5
|
125
|
440
|
356
|
165
|
20
|
440
|
264
|
165
|
20
|
6
|
150
|
440
|
356
|
165
|
20
|
440
|
364
|
165
|
20
|
|
