CNC/JIS UPVC/PPR/PE Flange

Date:2020-06-17  Click:344   Share to:


  • CNC/JIS UPVC/PPR/PE Flange

    Model

    Size(mm)

    D(mm)

    D1(mm)

    L(mm)

    Hole(mm)

    T(mm)

    L(mm)

    b

    N

    BMMVPTEFL001

    40  1 1/2''
    50  2''
    65  2 1/2''

    140
    155
    175

    105
    120
    140

    55
    63
    69

    19
    19
    19

    4
    4
    4

    17
    17
    18

    68
    76
    83

    BMMVPTEFL002

    80  3''
    100 4''
    125 5''

    185
    210
    250

    150
    175
    210

    72
    92
    112

    19
    19
    23

    8
    8
    8

    20
    20
    20

    86
    107
    130

    BMMVPTEFL003

    150  6''
    200  8''
    250  10''

    280
    330
    400

    240
    290
    355

    140
    172
    185

    23
    23
    25

    8
    12
    12

    22
    22
    24

    165
    195
    235

    BMMVPTEFL004

    300  12''

    445

    400

    230

    25

    16

    30

    295
