Model
|
Outside diameter(ØD)
|
ØA(mm)
|
H(mm)
|
C(mm)
|
ØX(mm)
|
ØR(mm)
|
Bolt hole
|
Inch
|
mm
|
ØG(mm)
|
N
|
Ød(mm)
|
BMMVPTENF001
|
1/2
|
20
|
95.2
|
52.4
|
14.3
|
38.1
|
34.9
|
66.7
|
4
|
15.9
|
BMMVPTENF002
|
3/4
|
25
|
117.5
|
57.1
|
15.9
|
47.6
|
42.9
|
82.5
|
19
|
BMMVPTENF003
|
1
|
30
|
123.8
|
61.9
|
17.5
|
54
|
50.8
|
88.9
|
BMMVPTENF004
|
1 1/4
|
38
|
133.3
|
65.1
|
19
|
63.5
|
63.5
|
98.4
|
BMMVPTENF005
|
1 1/2
|
44.5
|
155.6
|
68.3
|
20.6
|
69.8
|
73
|
114.3
|
8
|
22.2
|
BMMVPTENF006
|
2
|
57
|
165.1
|
69.8
|
22.2
|
84.1
|
92.1
|
127
|
19
|
BMMVPTENF007
|
2 1/2
|
76.1
|
190.5
|
76.2
|
25.4
|
100
|
104.8
|
149.2
|
22.2
|
BMMVPTENF008
|
3
|
88.9
|
209.5
|
79.4
|
28.6
|
117.5
|
127
|
168.3
|
BMMVPTENF009
|
4
|
108
|
254
|
85.7
|
31.8
|
146.1
|
157.2
|
200
|
BMMVPTENF010
|
5
|
133
|
279.4
|
98.4
|
34.9
|
177.8
|
185.7
|
234.9
|
BMMVPTENF011
|
6
|
159
|
317.5
|
36.5
|
206.4
|
215.9
|
269.9
|
12
|
BMMVPTENF012
|
8
|
219.1
|
381
|
111.1
|
41.3
|
260.4
|
269.9
|
330.2
|
25.4
|
BMMVPTENF013
|
10
|
267
|
444.5
|
117.5
|
47.6
|
320.7
|
323.8
|
387.3
|
16
|
28.6
|
BMMVPTENF014
|
12
|
323.9
|
520.7
|
130.2
|
50.8
|
374.6
|
381
|
450.8
|
31.7
|
BMMVPTENF015
|
14
|
368
|
584.2
|
142.9
|
54
|
425.4
|
425.1
|
514.3
|
20
|
BMMVPTENF016
|
16
|
419.1
|
647.7
|
146.1
|
57.2
|
482.6
|
482.6
|
571.5
|
34.9
|
BMMVPTENF017
|
18
|
457.2
|
711.2
|
158.7
|
60.3
|
533.3
|
533.4
|
628.6
|
24
|
BMMVPTENF018
|
20
|
508
|
774.7
|
161.9
|
63.5
|
587.4
|
584.2
|
685.8
|
BMMVPTENF019
|
24
|
610
|
914.4
|
168.3
|
69.8
|
701.7
|
692.1
|
812.8
|
41.3
|
Material:Stainelss steel,carbon steel
Size:DN 12/"-24"
Pressure:Class 300Lbs
Standard:ANSI B16.5
|
