ANSI Socket Welding Flange with Pressure 150-300Lbs
Date:2020-06-17 Click:257 Share to:
Model |
Pressure |
Outside diameter(ØD) |
ØA(mm) |
H(mm) |
C(mm) |
ØX(mm) |
ØR(mm) |
ØB1(mm) |
Y(mm) |
Bolt hole |
|||
Inch |
mm |
ØG(mm) |
N |
Ød(mm) |
|||||||||
BMMVPTENF001 |
150 |
1/2 |
20 |
88.9 |
15.9 |
11.1 |
30.2 |
34.9 |
20.2 |
9.5 |
60.3 |
4 |
15.9 |
BMMVPTENF002 |
3/4 |
25 |
98.4 |
12.7 |
38.1 |
42.9 |
25.2 |
11.1 |
69.8 |
||||
BMMVPTENF003 |
1 |
30 |
107.9 |
17.5 |
14.3 |
49.2 |
50.8 |
30.2 |
12.7 |
79.4 |
|||
BMMVPTENF004 |
1 1/4 |
38 |
117.5 |
20.6 |
15.9 |
58.7 |
63.5 |
38.3 |
14.3 |
88.9 |
|||
BMMVPTENF005 |
1 1/2 |
44.5 |
127 |
22.2 |
17.5 |
65.1 |
73 |
44.8 |
15.9 |
98.4 |
|||
BMMVPTENF006 |
2 |
57 |
152.4 |
25.5 |
19.1 |
77.8 |
92.1 |
57.4 |
17.5 |
120.6 |
19 |
||
BMMVPTENF007 |
2 1/2 |
76.1 |
177.8 |
28.6 |
22.2 |
90.5 |
104.8 |
76.5 |
19 |
139.7 |
|||
BMMVPTENF008 |
3 |
88.9 |
190.5 |
30.2 |
23.8 |
107.9 |
127 |
89.4 |
20.6 |
152.4 |
|||
BMMVPTENF009 |
4 |
108 |
228.6 |
33.3 |
134.9 |
157.2 |
108.5 |
23.8 |
190.5 |
8 |
|||
BMMVPTENF010 |
300 |
1/2 |
20 |
95.2 |
22.2 |
14.3 |
38.1 |
34.9 |
20.2 |
9.5 |
66.7 |
4 |
15.9 |
BMMVPTENF011 |
3/4 |
25 |
117.5 |
25.4 |
15.9 |
47.6 |
42.9 |
25.2 |
11.1 |
82.5 |
19 |
||
BMMVPTENF012 |
1 |
30 |
123.8 |
27 |
17.5 |
54 |
50.8 |
30.2 |
12.7 |
88.9 |
|||
BMMVPTENF013 |
1 1/4 |
38 |
133.3 |
19 |
63.5 |
63.5 |
38.3 |
14.3 |
98.4 |
||||
BMMVPTENF014 |
1 1/2 |
44.5 |
155.6 |
30.2 |
20.6 |
69.8 |
73 |
44.8 |
15.9 |
114.3 |
22.2 |
||
BMMVPTENF015 |
2 |
57 |
165.1 |
33.3 |
22.2 |
84.1 |
92.1 |
57.4 |
17.5 |
127 |
8 |
19 |
|
BMMVPTENF016 |
2 1/2 |
76.1 |
190.5 |
38.1 |
25.4 |
100 |
104.8 |
76.5 |
19 |
149.2 |
22.2 |
||
BMMVPTENF017 |
3 |
88.9 |
209.5 |
42.9 |
28.6 |
117.5 |
127 |
89.4 |
20.6 |
168.3 |
|||
BMMVPTENF018 |
4 |
108 |
254 |
47.6 |
31.8 |
146 |
157.2 |
108.5 |
23.8 |
200 |
|||
Material:Stainless steel
Size:1/2"-4"
Pressure:Class 150-300Lbs
Standard:ANSI B16.5
