Model
|
Outside diameter(ØD)
|
ØA(mm)
|
H(mm)
|
C(mm)
|
ØX(mm)
|
ØR(mm)
|
ØB(mm)
|
Bolt hole
|
Inch
|
mm
|
ØG(mm)
|
N
|
Ød(mm)
|
BMMVPTENF001
|
1/2
|
20
|
88.9
|
15.9
|
11.1
|
30.2
|
34.9
|
20.2
|
60.3
|
4
|
15.9
|
BMMVPTENF002
|
3/4
|
25
|
98.4
|
12.7
|
38.1
|
42.9
|
25.5
|
69.8
|
BMMVPTENF003
|
1
|
30
|
107.9
|
17.5
|
14.3
|
49.2
|
50.8
|
30.2
|
79.4
|
BMMVPTENF004
|
1 1/4
|
38
|
117.5
|
20.6
|
15.9
|
58.7
|
63.5
|
38.3
|
88.9
|
BMMVPTENF005
|
1 1/2
|
44.5
|
127
|
22.2
|
17.5
|
65.1
|
73
|
44.8
|
98.4
|
BMMVPTENF006
|
2
|
57
|
152.4
|
25.4
|
19.1
|
77.8
|
92.1
|
57.4
|
120.6
|
19
|
BMMVPTENF007
|
2 1/2
|
76.1
|
177.8
|
28.6
|
22.2
|
90.5
|
104.8
|
76.5
|
139.7
|
BMMVPTENF008
|
3
|
88.9
|
190.5
|
30.2
|
23.8
|
107.9
|
137
|
89.4
|
152.4
|
BMMVPTENF009
|
4
|
108
|
228.6
|
33.3
|
134.9
|
157.2
|
108.5
|
190.5
|
8
|
BMMVPTENF010
|
5
|
133
|
254
|
36.5
|
163.5
|
185.7
|
133.8
|
215.9
|
22.2
|
BMMVPTENF011
|
6
|
159
|
279.4
|
39.7
|
25.4
|
192.1
|
215.9
|
159.8
|
241.3
|
BMMVPTENF012
|
8
|
219.1
|
342.9
|
44.4
|
28.6
|
246.1
|
269.9
|
220.3
|
298.4
|
BMMVPTENF013
|
10
|
267
|
406.4
|
49.2
|
30.2
|
304.8
|
323.8
|
268.4
|
361.9
|
12
|
25.4
|
BMMVPTENF014
|
12
|
323.9
|
482.6
|
55.6
|
31.8
|
365.1
|
381
|
325.4
|
431.8
|
BMMVPTENF015
|
14
|
368
|
533.4
|
57.1
|
34.9
|
400
|
425.1
|
369.5
|
476.2
|
28.6
|
BMMVPTENF016
|
16
|
419.1
|
596.9
|
63.5
|
36.5
|
457.2
|
482.6
|
420.5
|
539.7
|
16
|
BMMVPTENF017
|
18
|
457.2
|
635
|
68.3
|
39.7
|
504.8
|
533.4
|
458.7
|
577.8
|
31.7
|
BMMVPTENF018
|
20
|
508
|
698.5
|
73
|
42.9
|
558.8
|
584.2
|
509.5
|
635
|
20
|
BMMVPTENF019
|
24
|
610
|
812.8
|
82.5
|
47.6
|
663.6
|
692.1
|
611.5
|
749.3
|
34.9
|
Material:Stainless steel
Size:DN 1/2"-24"
Pressure:Class 150Lbs
Standard:ANSI B16.5
|
