DZL series horizontal packaged steam boiler quickly
Date:2020-06-16 Click:503 Share to:
Model |
DZL1-0.7-AⅡ |
DZL2-1.25-AⅡ |
DZL4-1.25-AⅡ |
DZL6-1.25-AⅡ |
DZL10-1.25-AⅡ |
DZL15-1.25-AⅡ |
DZL20-1.25-AⅡ |
DZL1-1.0-AⅡ |
DZL2-1.6-AⅡ |
DZL4-1.6-AⅡ |
DZL6-1.6-AⅡ |
DZL10-1.6-AⅡ |
DZL15-1.6-AⅡ |
DZL20-1.6-AⅡ |
|
Rated evaporation capacity t/h |
1 |
2 |
4 |
6 |
10 |
15 |
20 |
Rated operation pressure MPa |
0.7/1.0 |
1.25/1.6 |
1.25/1.6 |
1.25/1.6 |
1.25/1.6 |
1.25/1.6 |
1.25/1.6 |
Rated steam temperature ℃ |
170/184 |
193/204 |
193/204 |
193/204 |
193/204 |
193/204 |
193/204 |
Feed water temperature ℃ |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
Heating area m2 |
3.5/20/10 |
6.5/40/17 |
11/88/17 |
16/118/50 |
17/200/131 |
35/332/200 |
53/415/213 |
Body water capacitym2 |
3.6 |
6.5 |
9.2 |
12.3 |
16.5 |
20 |
25 |
Boiler efficiency % |
>76 |
>78 |
>78 |
>80 |
>80 |
>80 |
>80 |
Main pipe diameter(DN) |
50 |
65 |
100 |
125 |
150 |
200 |
200 |
Fuel |
soft coal |
||||||
fuel consumption Kg/h |
167.9 |
330 |
655 |
870 |
1440 |
2240 |
2860 |
Overall demension after install |
6.0×3.2×4.2 |
5.7×3.9×4.9 |
6.8×3.6×5.1 |
8.1×5.2×6.3 |
9.8×5.7×6.3 |
10.4×5.2×8.1 |
11×5.6×8.6 |
