Model
|
BMMAERHHE001
|
distance between plates
|
2.5-15mm
|
Single plate heat exchange area
|
0.015㎡—3.8㎡
|
Port Size
|
DN25mm—500mm
|
Maximum installed area
|
2000㎡
|
Maximum processing flow
|
3600m3/h
|
Maximum working pressure
|
2.5MPa
|
Maximum working temperature
|
nomal 160℃,special 200℃
|
Plate thickness
|
0.5mm、0.6mm、0.7mm
|
Plate material
|
Stainless steel: 304,316 L, 317L, 321,310 S, N6, 254SMo etc.; titanium and titanium-palladium alloys Ti, Ti-Pd, nickel and nickel-based alloys such as C-276
|
Gasket Material
|
NBR,EPDM,FPM,Food EPDM,Food FPM,PTFE
|
|
