TM15A Type Soda Heat Exchanger
Date:2020-06-16 Click:318 Share to:
Model |
Type |
Version |
Dimension (mm) |
Maximum assembly area |
Over diameter |
|||||
L |
W |
H |
mm |
|||||||
BMMAERHHE001 |
BR3 |
H |
700 |
164 |
439 |
4 |
DN25 |
|||
BMMAERHHE002 |
BR6 |
H |
800 |
164 |
642.5 |
8 |
DN25 |
|||
BMMAERHHE003 |
BR140 |
H,V |
3450 |
1130 |
2589 |
850 |
DN300 |
|||
BMMAERHHE004 |
BR170 |
H,V |
3500 |
1130 |
2925 |
1400 |
DN300 |
|||
BMMAERHHE005 |
CM3 |
BH,BV |
750 |
168 |
496 |
6 |
DN30 |
|||
BMMAERHHE006 |
CM6 |
BH,BV,MH,MV |
1610 |
354 |
894 |
37 |
DN50 |
|||
BMMAERHHE007 |
CM10 |
BH,BV,MH,MV |
2400 |
480 |
1067 |
100 |
DN100 |
|||
BMMAERHHE008 |
CM25 |
BH,BV,MH,MV |
3300 |
606 |
1777 |
370 |
DN150 |
|||
BMMAERHHE009 |
CM20 |
BH,BV,MH,MV |
4050 |
760 |
2055 |
410 |
DN200 |
|||
BMMAERHHE010 |
CMX25 |
BH,BV |
3410 |
910 |
2659 |
1000 |
DN250 |
|||
BMMAERHHE011 |
TM10 |
H,V |
1800 |
475 |
1052 |
45 |
DN100 |
|||
BMMAERHHE012 |
TM15A |
H,V |
2300 |
600 |
1322 |
100 |
DN150 |
|||
BMMAERHHE013 |
TM15 |
H,V |
3300 |
600 |
1771 |
370 |
DN150 |
|||
BMMAERHHE014 |
TM20A |
H,V |
2400 |
740 |
1536 |
250 |
DN200 |
|||
BMMAERHHE015 |
TM20 |
H,V |
4050 |
740 |
2078 |
500 |
DN200 |
|||
BMMAERHHE016 |
CM6 |
MH,MV |
1610 |
354 |
894 |
37 |
DN50 |
|||
BMMAERHHE017 |
CM10 |
MH,MV |
2400 |
480 |
1067 |
100 |
DN100 |
|||
BMMAERHHE018 |
TM15A |
H,V |
2300 |
600 |
1322 |
100 |
DN150 |
|||
BMMAERHHE019 |
TM20A |
H,V |
2400 |
740 |
1536 |
250 |
DN200 |
|||
BMMAERHHE020 |
BL80 |
H,V |
3860 |
1000 |
1885 |
460 |
DN350/DN150 |
|||
BMMAERHHE021 |
BR140 |
H,V |
3450 |
1130 |
2589 |
850 |
DN300 |
|||
