Direct Type Screw Air Compressor
Date:2020-06-15 Click:332 Share to:
Direct Type Screw Air Compressor
Model |
|
DM-55AG/WG |
|||
Capacity FAD |
M3/min |
10.80 |
10.00 |
9.00 |
8.20 |
CFM |
382 |
353 |
318 |
290 |
|
Working pressure |
Bar |
7 |
8 |
10 |
12 |
psig |
102 |
116 |
145 |
174 |
|
Compression stage |
|
Single |
|||
Cooling mode |
|
A-Air cooling W-Water Cooling |
|||
Air discharge temperature |
℃ |
＜Ambient temperature+15℃(Air Cooling) |
|||
Noise level |
dB(A) |
±2 |
|||
Driving mode |
|
Direct Driven |
|||
Voltage |
V/ph/Hz |
380V 3Ph 50Hz as standard, also can be changed as customers’ requirement |
|||
Installed motor power |
KW |
55 |
|||
HP |
75 |
||||
Starting mode |
|
Y-▲ starting |
|||
Overall dimensions |
L(mm) |
1585 |
|||
W(mm) |
1170 |
||||
H(mm) |
1800 |
||||
Weight |
KGS |
1170 |
|||
Outlet pipe diameter |
Inch |
G2” |
|||
Water Inlet and Outlet |
Inch |
G1 |
|||
