Three Roller Chock
Three Roller Chock Drawing
Product No.
|
r
(mm)
|
A
(mm)
|
A1
(mm)
|
A2
(mm)
|
A3
(mm)
|
A4
(mm)
|
d
(mm)
|
Screw
No.
|
Weight(KG)
|
Cast
iron
|
Cast
Steel
|
BMMMERCTH-001
|
45
|
420
|
1430
|
480
|
190
|
|
33
|
8
|
288
|
266
|
BMMMERCTH-002
|
45
|
460
|
1570
|
550
|
220
|
|
33
|
8
|
361
|
352
|
BMMMERCTH-003
|
50
|
500
|
1700
|
420
|
240
|
1250
|
33
|
12
|
454
|
435
|
BMMMERCTH-004
|
50
|
530
|
1830
|
530
|
260
|
1330
|
33
|
12
|
568
|
522
|
BMMMERCTH-005
|
50
|
590
|
2070
|
560
|
300
|
1480
|
33
|
12
|
804
|
760
|
BMMMERCTH-006
|
55
|
640
|
2230
|
640
|
310
|
1640
|
39
|
12
|
1049
|
1051
|
Product No.
|
Wheel
Diameter
(mm)
|
Max.
tightwire
diameter (mm)
|
Rope
Circumference
(mm)
|
L
(mm)
|
B
(mm)
|
H(mm)
|
h(mm)
|
Cast
iron
|
Cast
steel
|
Cast
iron
|
Cast
steel
|
BMMMERCTH-001
|
150
|
20.6
|
225
|
1520
|
280
|
250
|
235
|
55
|
40
|
BMMMERCTH-002
|
170
|
30.5
|
250
|
1660
|
310
|
273
|
260
|
58
|
45
|
BMMMERCTH-003
|
185
|
33.5
|
275
|
1880
|
340
|
285
|
270
|
60
|
45
|
BMMMERCTH-004
|
200
|
37.5
|
300
|
1930
|
360
|
295
|
280
|
65
|
50
|
BMMMERCTH-005
|
230
|
43.5
|
325
|
2170
|
400
|
320
|
305
|
65
|
50
|
BMMMERCTH-006
|
250
|
48.5
|
350
|
2340
|
420
|
340
|
325
|
70
|
55
|
|
