Double Roller Chock

Product No.

r
(mm)

A
(mm)

A1
(mm)

A2
(mm)

A3
(mm)

A4
(mm)

d
(mm)

Screw
No.

Weight(KG)

Cast
iron

Cast
Steel

BMMMERCDO-001

30

240

580

110

115

17

8

50

44

BMMMERCDO-002

35

300

730

120

140

21

8

96

82

BMMMERCDO-003

40

360

860

140

165

25

8

141

133

BMMMERCDO-004

45

420

1010

170

190

30

8

222

215

BMMMERCDO-005

45

460

1110

230

220

30

8

300

274

BMMMERCDO-006

50

500

1200

240

240

33

8

374

329

BMMMERCDO-007

50

530

1300

260

260

800

33

12

444

417

BMMMERCDO-008

50

590

1480

280

300

900

33

12

589

547

BMMMERCDO-009

55

640

1590

300

310

980

39

12

721

687

Product No.

Diameter
of
Wheel (mm)

Max.diameter
of
tightwire (mm)

Circumference
of
rope(mm)

L
(mm)

B
(mm)

H(mm)

h(mm)

Cast
iron

Cast
steel

Cast
iron

Cast
steel

BMMMERCDO-001

75

15.5

1235

640

175

168

158

40

30

BMMMERCDO-002

100

19.5

175

800

210

190

180

45

35

BMMMERCDO-003

125

22.5

200

940

245

217

207

50

40

BMMMERCDO-004

150

26

225

1100

280

250

235

55

40

BMMMERCDO-005

170

30.5

250

1200

310

273

260

58

45

BMMMERCDO-006

185

33.5

275

1300

34

285

270

60

45

BMMMERCDO-007

200

37.5

300

1400

360

295

280

65

50

BMMMERCDO-008

230

43.5

325

1580

400

320

305

65

50

BMMMERCDO-009

250

48.5

350

1700

420

340

325

70

55
