Engineering Ship Fairlead

Product No.

Wheel
diameter
D(mm)

Diameter of
horizontal wheel
D1(mm)

Max.diameter
of tightwire
Φ(mm)

L
(mm)

B
(mm)

H
(mm)

b
(mm)

h1
(mm)

h2
(mm)

l
(mm)

Screw
diameter
d(mm)

Model A

Model B

BMMMEFESF-001

100

85

19.5

540

340

240

240

250

220

50

200

22

BMMMEFESF-002

150

120

26

760

460

340

340

340

320

65

230

26

BMMMEFESF-003

200

150

37.5

980

580

430

440

430

410

80

380

32

BMMMEFESF-004

250

200

48.5

1220

740

520

550

540

500

110

480

39

BMMMEFESF-005

300

250

56

1460

900

620

675

650

590

135

580

39
