Five Roller Fairlead((A)

Main Dimensions

Product No.

a
(mm)

b
(mm)

c
(mm)

d
(mm)

e
(mm)

f
(mm)

g
(mm)

h
(mm)

i
(mm)

k
(mm)

l
(mm)

m
(mm)

BMMMERFFI-A001

180

100

253

80

446

700

10

510

125

170

356

356

BMMMERFFI-A002

230

130

308

100

546

900

10

625

150

210

446

446

BMMMERFFI-A003

250

130

363

120

626

1000

15

710

175

250

506

506

BMMMERFFI-A004

280

160

423

140

716

1100

20

825

215

288

576

576

BMMMERFFI-A005

300

160

518

180

836

1300

25

975

260

366

676

676

BMMMERFFI-A006

320

180

660

245

1030

1450

35

1200

335

500

830

830

BMMMERFFI-A007

400

250

788

300

1236

1800

45

1465

405

608

1016

1016

Product No.

Rated
Towing
Pull

Rope
Φ

Breaking
Strength
of Wire

Wire
Size
(mm)

Weight
KG

BMMMERFFI-A001

20KN

-12mm

150KN

12

125

BMMMERFFI-A002

30KN

-16mm

220KN

16

160

BMMMERFFI-A003

50KN

-20mm

350KN

20

400

BMMMERFFI-A004

80KN

-24mm

500KN

24

750

BMMMERFFI-A005

120KN

-32mm

800KN

32

860

BMMMERFFI-A006

200KN

-40mm

1150KN

40

1550

BMMMERFFI-A007

320KN

-48mm

1750KN

48

2700
