Three Roller Fairlead
Three Roller Fairlead Drawing
Product No.
|
A
(mm)
|
C
(mm)
|
D
(mm)
|
E
(mm)
|
F
(mm)
|
G
(mm)
|
H
(mm)
|
I
(mm)
|
K
(mm)
|
L
(mm)
|
|
|
BMMMERFTH-001
|
180
|
650
|
80
|
446
|
170
|
10
|
456
|
208
|
80
|
356
|
BMMMERFTH-002
|
230
|
800
|
100
|
546
|
210
|
10
|
571
|
258
|
100
|
446
|
BMMMERFTH-003
|
250
|
900
|
120
|
626
|
250
|
15
|
656
|
308
|
120
|
506
|
BMMMERFTH-004
|
280
|
1,000
|
140
|
716
|
288
|
20
|
726
|
328
|
120
|
576
|
BMMMERFTH-005
|
300
|
1,200
|
180
|
836
|
366
|
25
|
852
|
398
|
140
|
676
|
BMMMERFTH-006
|
320
|
1,350
|
245
|
1,030
|
500
|
35
|
1,035
|
505
|
180
|
830
|
BMMMERFTH-007
|
400
|
1,700
|
300
|
1,236
|
610
|
45
|
1,260
|
583
|
200
|
1,016
|
Product No.
|
Rated
towing
pull
|
Rope
Φ
|
Wire
Size
(mm)
|
Weight
|
|
|
BMMMERFTH-001
|
20KN
|
-12mm
|
12
|
75KN
|
BMMMERFTH-002
|
30KN
|
-16mm
|
16
|
130KN
|
BMMMERFTH-003
|
50KN
|
-20mm
|
20
|
220KN
|
BMMMERFTH-004
|
80KN
|
-24mm
|
24
|
320KN
|
BMMMERFTH-005
|
120KN
|
-32mm
|
32
|
580KN
|
BMMMERFTH-006
|
200KN
|
-40mm
|
40
|
1,100KN
|
BMMMERFTH-007
|
320KN
|
-48mm
|
48
|
2,210KN
|
|
