Single Cruciform Bollards (JIS F-2804 Cross Bitt)

Date:2020-06-12  Click:460   Share to:

  • Single Cruciform Bollards (JIS F-2804 Cross Bitt)

    Single Cruciform Bollards (JIS F-2804 Cross Bitt)
    Single Cruciform Bollards (JIS F-2804 Cross Bitt)

    Single Cruciform Bollards (JIS F-2804 Cross Bitt)
    Single Cruciform Bollards (JIS F-2804 Cross Bitt)Drawing



    Product No.

    Nominal Dia.(mm)

    Dimension(mm)

    Wire Rope Dia.(mm)

    H

    h

    B

    D

    D1

    D2

    D3

    Weight (kg)

    BMDM-SCB001

    150

    480

    280

    460

    165

    114

    206

    158

    33

    16

    BMDM-SCB002

    200

    560

    320

    520

    216

    165

    256

    206

    60

    22

    BMDM-SCB003

    250

    640

    360

    610

    267

    216

    308

    256

    102

    28

    BMDM-SCB004

    300

    680

    380

    660

    318

    267

    360

    308

    154

    34

    BMDM-SCB005

    350

    720

    420

    720

    355

    267

    400

    312

    186

    38
