TC16 flat bed CNC lathe

TC16 flat bed CNC lathe features:

1. The main shaft adopts a thermally symmetric structure and is equipped with a main shaft heat dissipation mechanism, so that it has good precision stability.

2. Equipped with Italy BF 12 station enlarged cutter head tool holder, which can meet the processing of different needs and solve the tool interference well.

3. The tailstock is a programmable servo-controlled tailstock, which is convenient and reliable, and can well realize factory automation processing.

Item	unit	TC20 parameters	TC16 parameters
Large swing diameter on the bed/saddle	mm	Φ500/Φ320	Φ500
zui large turning length	mm	500	290
zui large turning diameter	mm	Φ370	Φ260
zui large bar diameter	mm	Φ51	Φ50
Hydraulic chuck diameter	mm	8〞	6〞
Spindle head type	GB5900.1	A2-6	A2-6
Spindle taper hole specifications		1:20	1:20
Spindle through hole diameter	mm	Φ62	Φ66
Spindle speed	r/min	50～4500	40～4200
Main motor power (continuous/30 minutes)	kW	11/15	5.5/7.5
Sleeve diameter/stroke	mm	Φ90/100	Φ70/80
*Taper (standard/active spindle structure)	MT No.	5/4	4
slope	DEG	45°	30°
Travel distance X/Z	mm	210/560	160/330
Fast moving speed X/Zm	m/min	30/30	24/27
Number of knives		12	8
Tool size (turning/boring)	mm	25×25/Φ40	25×25/Φ32
power supply	kVA	45	23
Volume (length × width × height)	mm	4426X2165X2048 (with chip conveyor)	1866X2226X1661 (with chip conveyor)
total weight	kg	5500	3600
