Double Bollards BSMA-12

Double Bollards BSMA-12

Double Bollards BSMA-12 Drawing

Product No.

F

Dimension(mm)

Weight(kg)

Tube

Plate

L1

L2

H1

H2

B

D2

BMDM-DBBSMA-001

M

T

D1

S

D1

S

BMDM-DBBSMA-002

4.06

12

140

10

140

10

560

320

200

75

200

150

40

BMDM-DBBSMA-003

5.85

12

168

10

168

10

720

400

250

90

250

200

66

BMDM-DBBSMA-004

7.96

17

219

10

219

10

900

500

300

100

300

250

97

BMDM-DBBSMA-005

13.2

30

273

10

273

10

1130

630

380

125

380

300

145

BMDM-DBBSMA-006

19.7

50

324

12.5

324

12.5

1430

800

480

150

480

380

309

BMDM-DBBSMA-007

33.5

100

406

20

406

20

1800

1000

600

175

600

480

735

BMDM-DBBSMA-008

55.4

130

508

20

508

20

2250

1250

750

200

750

600

1148

BMDM-DBBSMA-009

82.8

160

610

20

610

20

2830

1570

940

225

940

730

1673

-Maximum persissible load in bollard F tonnes

-When mooring M tonnes, towing T tonnes.
