Double Bollards DIN 82607

Double Bollards DIN 82607

Double Bollards DIN 82607 Drawing

Product No.

Rated Towing Pull kN

TubeD1

B

D2

E

H1

H2

S2

A

Weight(kg)

BMDM-DBDIN-001

10

139.7*6.3

130

160

430

370

105

5

4

20.6

BMDM-DBDIN-002

20

219.1*8.0

180

242

570

475

115

6

4

52.3

BMDM-DBDIN-003

32

273.0*10.0

250

300

700

570

135

8

5

99.5

BMDM-DBDIN-004

50

323.9*10.0

300

355

880

670

150

8

6

145.4

BMDM-DBDIN-005

80

355.6*14.2

330

390

1050

780

175

10

8

259.4

BMDM-DBDIN-006

120

457.0*16.0

420

490

1200

860

195

16

12

437

BMDM-DBDIN-007

200

508.0*17.5

470

545

1350

970

230

16

-

571

BMDM-DBDIN-008

320

559.0*20.0

530

600

1400

1000

270

16

-

830
