ZLY Horizontal Type Double Stage Vacuum Oil Purifier

Date:2020-06-12  Click:426   Share to:

    • ZLY Horizontal Type Double Stage Vacuum Oil Purifier

    ZLY Horizontal Type Double Stage Vacuum Oil Purifier



    Item Unit BMMAWOHO-001 BMMAWOHO-002 BMMAWOHO-003 BMMAWOHO-004 BMMAWOHO-005
    Flowrate L/min ≥ 100 ≥ 150 ≥ 200 ≥ 250 ≥ 300
    Work pressure Mpa 0~0.5
    vacuum degree Pa ≤ 100
    voltage V 50HZ 380V
    Heating power KW 48 72 90 108 135
    Total power KW 58 85 105 128 153
    Oil temperature range ℃ 20~80
    Gas content % ≤ 0.10
    Water content ppm ≤ 2.0
    Precision µm 1~2
    Breakdown voltage KV ≥ 75
    Work noise dB(A) ≤ 75 ≤ 80 ≤ 85
    Weight kg 1760 2000 2200 2350 2500
    Size mm 1600*1300*1750 1700*1400*1800 1800*1500*1800 2000*1700*1900 2000*1800*2000
