GZL Double Stage Vacuum Static Electricity Oil Purifier

Date:2020-06-12  Click:328   Share to:

    • GZL Double Stage Vacuum Static Electricity Oil Purifier

    GZL Double Stage Vacuum Static Electricity Oil Purifier



    Name Units BMMAEWOVF-001 BMMAEWOVF-002 BMMAEWOVF-003 BMMAEWOVF-004 BMMAEWOVF-005
    Capacity L/h 3000 6000 9000 12000 18000
    Vacuum Degree Pa ≤133
    Work Pressure Mpa 0.05 ～ 0.5
    Temperature ℃ 40 ～ 70
    Heating Power kW 36 72 108 132 198
    Total Power kW 39 76 113 138 214
    Power Supply 　 ～ 380V 50Hz
    Electric Field Strength V/m 900000
    Breakdown Voltage kV ≥85
    Impurity Size μm 0.05
    Cleanliness NAS1638 4
    Water Content PPm ≤6
    Gas Content % 0.1
    Weight kg 1800 2200 3300 3600 4200
    Overall Length mm 2300 2500 2600 2600 2800
    Width 1700 1700 1700 1700 1800
    Height 2000 2200 2300 2400 2500
