PP High Performance Tension Rope
Product No.
|
Size
|
PP High Performance Tension Rope Breaking Load(Tons)
|
Dia mm
|
Cir inch
|
KG/220M
|
8-Strand
|
12-srand
|
BMMMEMRHP-001
|
20
|
2-1/2
|
38
|
6
|
6.3
|
BMMMEMRHP-002
|
28
|
3-1/2
|
86
|
16.3
|
16.5
|
BMMMEMRHP-003
|
36
|
4-1/2
|
129
|
21
|
21.8
|
BMMMEMRHP-004
|
40
|
5
|
158
|
26.2
|
27.5
|
BMMMEMRHP-005
|
48
|
6
|
229
|
36.3
|
38
|
BMMMEMRHP-006
|
52
|
6-1/2
|
268
|
43
|
45
|
BMMMEMRHP-007
|
56
|
7
|
312
|
48.1
|
50
|
BMMMEMRHP-008
|
60
|
7-1/2
|
359
|
55.5
|
58.3
|
BMMMEMRHP-009
|
64
|
8
|
407
|
62.1
|
65.2
|
BMMMEMRHP-010
|
72
|
9
|
515
|
77.7
|
81.6
|
BMMMEMRHP-011
|
80
|
10
|
638
|
95.6
|
100
|
BMMMEMRHP-012
|
88
|
11
|
772
|
116
|
122
|
BMMMEMRHP-013
|
96
|
12
|
916
|
136
|
142
|
BMMMEMRHP-014
|
104
|
13
|
1070
|
158
|
165
|
BMMMEMRHP-015
|
112
|
14
|
1250
|
184
|
192
|
BMMMEMRHP-016
|
120
|
15
|
1430
|
205
|
213
|
BMMMEMRHP-017
|
128
|
16
|
1769
|
253
|
260
|
BMMMEMRHP-018
|
152
|
19
|
2456
|
307
|
315
|
1 ton= 9.8kn 1 dan=0.01kn 1Ktex=1g/m
|
Description:Using PP High Performance Rope fiber designed for high tension work loading.The breaking strength is 30% stronger then normal polypropylene.Constructure can be 8 and 12-Strand .
Applications:The products are mainly used in fields of shipbuilding like dock lines and anchor lines, ocean transportation, national defense and military industry, sea petroleum and harbor operation etc.
Specific gravity :0.91.It can float in water .Melting point : 165℃.High strength and easy operation.good abrasion resistance.
Remarks for marine rope:
1. When Ordering,please specify whether eyes should be spliced on one or both ends of the ropes, and if the eyes should be covered With canvas or PVC.
2 .Certificates:CCS,ABS,BV,NK,GL,LR,DNV,SR etc are provided when requiring."
|
