YLG Series Pressure Water Tank

YLG Series Pressure Water Tank

Application

The pressure water tank can be used to provide fresh water for living and cleaning of ship and drilling platforms.

Main Technical Parameters

Capacity: A(0.12m³, 0.2 m³,0.3 m³)

        B(0.5 m³,1.0 m³)

        C(0.5 m³,1.0 m³,1.5 m³,2.0 m³,3.0 m³)

Working Pressure: 0.6MPa

Design Pressure: 0.7 MPa

Strength Test Pressure: 1.05MPa

Tightness test pressure: 0.875MPa

Safety valve open pressure: 0.63MPa

Principle Description

  This device using pumps (pumps by the shipyard package) into the tank water to the compressed air pressure of the body, so that the cabinet body of water to maintain the appropriate pressure for used on board.

Main Technical parameters, outline, mounting and connected dimension see the above drawing and the following table:
