Hydraulic Slewing Crane (Explosion-proof Type)

Date:2020-06-11 Click:323 Share to:

Hydraulic Slewing Crane (Explosion-proof Type)

Hydraulic Slewing Crane (Explosion-proof Type)
Main Technical Specification
Product No.	Safety Load （t）	Working range （m）	Lifting speed （m/min）	Amplitude time （s）	Rotation speed （rpm）	Rotation angle （°）	Motor Power （KW）
BMMDMHSCE-001	1	2-8	0-20	≤50	0.8	360	11
BMMDMHSCE-002	2	2.5-14	0-20	≤50	0.8	360	15
BMMDMHSCE-003	3	3-16	0-20	≤60	0.8	360	18.5
BMMDMHSCE-004	5	4.5-22	0-20	≤75	0.8	360	30
BMMDMHSCE-005	8	4-20	0-20	≤70	0.8	360	37
BMMDMHSCE-006	10	4-20	0-20	≤70	0.8	360	45
BMMDMHSCE-007	20	4-20	0-20	≤70	0.8	360	55
Main Dimensions
Product No.		L	D1	D2	D3	n-ф	L1
BMMDMHSCE-001		3200	740	800	880	24-ф20	1000
BMMDMHSCE-002		3200	740	800	880	24-ф20	1200
BMMDMHSCE-003		4500	1000	1150	1250	36-ф26	1200
BMMDMHSCE-004		5500	1600	1720	1830	54-ф30	1500
BMMDMHSCE-005		6000	1900	2090	2240	48-ф33	1500
BMMDMHSCE-006		6000	1900	2090	2240	48-ф33	1500
BMMDMHSCE-007		6500	2100	2200	2350	58-ф42	1500
All the details including Drawing and Data are changeable according to customer's requirements.
