Quick Details
Max. Lifting Height:9.5m
Warranty:12 months
After-sales Service Provided:Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Free spare parts
Feature:Other
Condition:New
Application:Narrow Space
Rated Loading Capacity:3 tons
Rated Lifting Moment:3tons x 1.3m
Span:4m
Place of Origin:Jiangsu, China (Mainland)
Brand Name: FUKANG
Boom Length:8.2m
Slewing angle:360 Degree Hydraulic Slewing
Operation system:Wireless remote control and manual
Safety system:Safe load moment limiter
Crane screen:Intelligent display screen
Boom type:Automatic 4 sections
Overseas training:Yes
Warranty time:1 year
After-sales Service:Engineers available to service
Product Performance Parameter
|
YQ-3T.Main Technical Parameters of Crawler Hydraulic Crane
|
No.
|
Name of Parameter
|
Unit
|
Figure
|
Remarks
|
1
|
Maximum rated lifting weight × amplitude
|
t×m
|
3×3
|
|
2
|
Crane's Maximum Weight
|
t
|
5
|
|
3
|
Boom Length
|
m
|
11
|
|
4
|
Basic Arm Length
|
m
|
5
|
|
5
|
Extendable Arm Length
|
m
|
6
|
|
6
|
Maximum Lifting Angle
|
°
|
80
|
|
7
|
Operation Mode
|
|
Totally Hydraulic
|
|
8
|
Windless
|
m/min
|
38
|
Fourth Layer of Reel
|
9
|
Variable Speed
|
m/min
|
45
|
|
10
|
Swing Speed
|
rpm
|
1～2
|
|
11
|
Walking Speed
|
km/h
|
1～1.68
|
|
12
|
Crawling Ability
|
%
|
30
|
|
13
|
Grounding Pressure
|
MPa
|
0.09
|
|
14
|
Dimensions(Length ×Width×Height)
|
m
|
5.9×2.0×3.0
|
|
15
|
Main Lift Rate (4)
|
t
|
9
|
|
16
|
Engine Rated Power / Speed
|
kw/r/min
|
20/3500
|
|
17
|
Maximum Output Torque / Speed
|
Nm/r/min
|
260/1600 ～2000
|
|
18
|
Emission Standards
|
|
EU Stage II
|
|
19
|
Environmental Radiation Noise during Work
|
Db
|
≤107
|
|
20
|
Operating Indoor Noise during Work
|
Db
|
≤85
|
|
|
