DZB Series Marine Electrical Pump

Date:2020-06-10  Click:307   Share to:

    • DZB Series Marine Electrical Pump

    DZB Series Marine Electrical Pump

    DZ series pumps are horizontal single cylinder electric plunger pump, which can be used to suck out such liquid as oily water, bilge, fresh water, sea water etc, without hard particle or fiber impurities and below 85℃.

    The designing and making of this product is up to standard of CB/T3160-92 marine electric plunger oily water delivery pump. Marine products are entirely recognized by CCS.

    DZ series pumps are especially fit for complement use of oily water processing plant, reducing oil-water emulsifiability, increasing separation effect. It features in working safely, convenient operation, easy maintenance, delicate manufacturing, good durability and economic results.

    Main Technical Performance parameter

    Type

    flowrale
    m3/h

    Pressure
    MPa

    High absorption
    m

    Between the number of
    /min

    Intel Pipe Diameter
    mm

    pump weight
    KW

    Diameter
    L×M×H

    DZB-100

    0.1

    0.3

    6

    55

    15

    0.12

    249×210×313

    DZB-250

    0.25

    0.3

    6

    56

    25

    0.18

    310×230×340

    DZB-500

    0.5

    0.3

    6

    50

    25

    0.25

    370×255×370

    DZB-1000

    1

    0.3

    6

    50

    40

    0.37

    390×268×390

    DZB-2000

    2

    0.3

    6

    70

    40

    0.75

    452×300×442

    DZB-3000

    3

    0.3

    6

    70

    50

    1.1

    609×356×515

    DZB-4000

    4

    0.3

    6

    60

    60

    1.5

    718×395×535

    DZB-5000

    5

    0.3

    6

    70

    60

    1.5

    718×395×535
