BJ-20B Portable Diesel Engine Fire Pump

BJ-20B Portable Diesel Engine Fire Pump

BJ-20B  Portable Diesel Engine Fire Pump has been mounted with R2V840 diesel engine and the single-level centrifugal pumps . It has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade, forest fire brigade, towns, rural areas, the mining industry and obligation fire brigade.

Technical parameters:

Appearance dimension  650×580×650mm;

Inlet size      Φ80mm;

Outlet sizeΦ65mm;

Device weight≤102kg;

Maximum output power22HP/3600r/min;

Starting methodelectric start;

Max capacity&pressure1400L/min/0.63Mpa;

Pump priming time≤20s;

Maximum suction depth9m

Pump lift72m
