BJ-22B Portable Fire Pump

BJ-22B Portable Fire Pump

BJ-22B Portable Fire Pump is powered by R2V870 DIESEL engine and the single-level centrifugal pumps. The hand carrying mobile fire pump can be divided into electric start styles. It can be self-charge during work. It has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade, forest fire brigade, towns, rural areas, the mining industry and obligation fire brigade.

Technical parameters:

Appearance dimension  650×610×650mm;

Pump Inlet           Φ80mm;

Pump outlet        Φ65mm;

Device weight         ≤105kg

Maximum output power   25Hp/3600r/min;

Starting method     electric start;

Max. flow rate&pressure      2000L/min/MPa;

Pump priming time   ≤20s;

Maximum suction depth   7m

Pump lift    80m
