CIS/IS single stage centrifugal pumps

Date:2020-06-09 Click:271 Share to:

Model	Type	Flow	head	pressure	Shaft power	Motor		efficiency	NPSH	D.of lmpel	Pump diameter
		Q	H	n	Pa	power	Type	efficiency	NPSH	D.of lmpel	Inlet
		m3/h	m	r/min	kW	kW	Type	%	m	mm	mm	mm
BMMAETECP001	IS50-32-125	7.5	22	2980	0.96	2.2	Y90L-2	47	2	127	50	32
		12.5	20		1.13			60
		15	18.5		1.26			60
BMMAETECP002	IS50-32J-125	3.75	5.4	1480	0.13	0.55	Y801-4	43	2	127	50	32
		6.3	5		0.16			54
		7.5	4.6		0.17			55
BMMAETECP003	IS50-32-125A	11.2	16	2980	0.98	1.5	Y90S-2	50	2	115	50	32
BMMAETECP004	IS50-32J-125A	5.6	4	1480	0.12	0.55	Y801-4	52	2	115	50	32
BMMAETECP005	IS50-32-160	7.5	34.3	2980	1.59	3	Y100L-2	44	2	154	50	32
		12.5	32		2.02			54
		15	29.6		2.16			56
BMMAETECP006	IS50-32J-160	3.75	8.5	1480	0.25	0.55	Y801-4	35	2	154	50	32
		6.3	8		0.29			48
		7.5	7.5		0.31			49
BMMAETECP007	IS50-32-160A	11.7	28	2980	1.72	3	Y100L-2	52	2	146	50	32
BMMAETECP008	IS50-32J-160A	5.9	7	1480	0.24	0.55	Y801-4	46	2	146	50	32
BMMAETECP009	IS50-32-160B	10.8	24	2980	1.41	2.2	Y90L-2	50	2	136	50	32
BMMAETECP010	IS50-32J-160B	5.4	6	1480	0.2	0.55	Y801-4	44	2	136	50	32
BMMAETECP011	IS50-32-200	7.5	52.5	2980	2.82	5.5	Y132S1-2	38	2	198	50	32
		12.5	50		3.55			48
		15	48		3.84			51
BMMAETECP012	IS50-32J-200	3.75	13.1	1480	0.41	0.75	Y802-4	33	2	198	50	32
		6.3	12.5		0.51			42
		7.5	12		0.56			44
BMMAETECP013	IS50-32-200A	11.7	44	2980	3.05	4	Y112M-2	46	2	183	50	32
BMMAETECP014	IS50-32J-200A	5.9	11	1480	0.44	0.75	Y802-4	40	2	183	50	32
BMMAETECP015	IS50-32-200B	10.8	38	2980	2.54	4	Y112M-2	44	2	170	50	32
BMMAETECP016	IS50-32J-200B	5.4	9.5	1480	0.37	0.55	Y801-4	38	2	170	50	32
BMMAETECP017	IS50-32-250	7.5	82	2980	5.88	11	Y160M1-2	28.5	2	243	50	32
		12.5	80		7.17			38
		15	78.5		7.82			41
BMMAETECP018	IS50-32J-250	3.75	20.5	1480	0.91	1.5	Y90L-4	23	2	243	50	32
		6.3	20		1.07			32
		7.5	19.5		1.14			35
BMMAETECP019	IS50-32-250A	11.7	70	2980	6.2	7.5	Y132S2-2	36	2	231	50	32
BMMAETECP020	IS50-32J-250A	5.9	17.5	1480	0.94	1.5	Y90L-4	30	2	231	50	32
BMMAETECP021	IS50-32-250B	10.8	60	2980	5.19	7.5	Y132S2-2	34	2	216	50	32
BMMAETECP022	IS50-32J-250B	5.4	15	1480	0.79	1.1	Y90S-4	28	2	216	50	32
BMMAETECP023	IS65-50-125	15	21.8	2980	1.54	3	Y100L-2	58	2	126	65	50
		25	20		1.97			69
		30	18.5		2.22			68
BMMAETECP024	IS65-50J-125	7.5	5.35	1480	0.21	0.55	Y801-4	53	2	126	65	50
		12.5	5		0.27			64
		15	4.7		0.3			65
BMMAETECP025	IS65-50-125A	22.4	16	2980	1.46	2.2	Y90L-2	67	2.5	116	65	50
BMMAETECP026	IS65-50J-125A	11.2	4	1480	0.2	0.55	Y801-4	62	2	116	65	50
BMMAETECP027	IS65-50-160	15	35	2980	2.65	5.5	Y132S1-4	54	2	161	65	50
		25	32		3.35			65
		30	30		3.71			66
BMMAETECP028	IS65-50J-160	7.5	8.8	1480	0.36	0.75	Y802-4	50	2	161	65	50
		12.5	8		0.45			60
		15	7.2		0.49			60
BMMAETECP029	IS65-50-160A	23.4	28	2980	2.83	4	Y112M-2	63	2	152	65	50
BMMAETECP030	IS65-50J-160A	11.7	7	1480	0.38	0.75	Y802-4	58	2	152	65	50
BMMAETECP031	IS65-50-160B	21.7	24	2980	2.33	4	Y112M-2	61	2	142	65	50
BMMAETECP032	IS65-50J-160B	10.8	6	1480	0.32	0.55	Y801-4	56	2	142	65	50
BMMAETECP033	IS65-40-200	15	53	2980	4.42	7.5	Y132S2-2	49	2	195	65	40
		25	50		5.67			60
		30	47		6.29			61
BMMAETECP034	IS65-40J-200	7.5	13.2	1480	0.63	1.1	Y90S-4	43	2	195	65	40
		12.5	12.5		0.77			55
		15	11.8		0.85			57
BMMAETECP035	IS65-40-200A	23.4	44	2980	4.83	7.5	Y132S2-2	58	2	185	65	40
BMMAETECP036	IS65-40J-200A	11.7	11	1480	0.66	1.1	Y90S-4	53	2	185	65	40
BMMAETECP037	IS65-40-200B	21.7	38	2980	4.01	5.5	Y132S1-2	56	2	173	65	40
BMMAETECP038	IS65-40J-200B	10.8	9.5	1480	0.55	1.1	Y90S-4	51	2	173	65	40
BMMAETECP039	IS65-40-250	15	82	2980	9.05	15	Y160M2-2	37	2	247	65	40
		25	80		10.89			50
		30	78		12.02			53
BMMAETECP040	IS65-40J-250	7.5	21	1480	1.23	2.2	Y100L1-4	35	2	247	65	40
		12.5	20		1.48			46
		15	19.4		1.65			48
BMMAETECP041	IS65-40-250A	23.4	70	2980	9.29	15	Y160M2-2	48	2	236	65	40
BMMAETECP042	IS65-40J-250A	11.7	17.5	1480	1.27	2.2	Y100L1-4	44	2	236	65	40
BMMAETECP043	IS65-40-250B	21.7	60	2980	7.71	11	Y160M1-2	46	2	220	65	40
BMMAETECP044	IS65-40J-250B	10.8	15	1480	1.05	1.5	Y90L-4	42	2	220	65	40
BMMAETECP045	IS65-40-315	15	127	2980	18.5	30	Y200L1-2	28	2.5	307	65	40
		25	125		21.3			40
		30	123		22.8			44
BMMAETECP046	IS65-40J-315	7.5	32.3	1480	2.64	4	Y112M-4	25	2.5	307	65	40
		12.5	32		2.94			37
		15	31.7		3.16			41
BMMAETECP046	IS65-40J-315	7.5	32.3	1480	2.64	4	Y112M-4	25	2.5	307	65	40
		12.5	32		2.94			37
		15	31.7		3.16			41
BMMAETECP047	IS65-40-315A	23.9	114	2980	19.53	30	Y200L1-2	38	2.5	297	65	40
BMMAETECP048	IS65-40J-315A	11.9	28.5	1480	2.64	4	Y112M-4	35	2.5	297	65	40
BMMAETECP049	IS65-40-315B	22.7	103	2980	17.69	22	Y180M-2	36	2.5	281	65	40
BMMAETECP050	IS65-40J-315B	11.3	25.8	1480	2.41	4	Y112M-4	33	2.5	281	65	40
BMMAETECP051	IS65-40-315C	21.4	92	2980	15.77	18.5	Y160L-2	34	2.5	269	65	40
BMMAETECP052	IS65-40J-315C	10.7	23	1480	2.16	3	Y100L2-4	31	2.5	269	65	40
BMMAETECP053	IS80-65-125	30	22.5	2980	2.87	5.5	Y132S1-2	64	3	133	80	65
		50	20		3.63			75
		60	18		3.97			74
BMMAETECP054	IS80-65J-125	15	5.6	1480	0.42	0.75	Y802-4		2.5	133	80	65
		25	5		0.48
		30	4.5		0.51			55
BMMAETECP055	IS80-65-125A	44.7	16	2980	2.67	4	Y112M-2	69	2.5	122	80	65
BMMAETECP056	IS80-65J-125A	22.4	4	1480	0.35	0.55	Y801-4	69	2.5	122	80	65
BMMAETECP057	IS80-65-160	30	36	2980	4.82	7.5	Y132S2-2	61	2.5	163	80	65
		50	32		5.97			73
		60	29		6.58			72
BMMAETECP058	IS80-65J-160	15	9	1480	0.67	1.5	Y90L-2	55	2.5	163	80	65
		25	8		0.79			69
		30	7.2		0.87			68
BMMAETECP059	IS80-65-160A	46.8	28	2980	5.03	7.5	Y132S2-2	71	2.5	155	80	65
BMMAETECP060	IS80-65J-160A	23.4	7	1480	0.67	1.1	Y90S-4	67	2.5	155	80	65
