CO2 Extinguishing System

Date:2020-06-08 Click:406 Share to:

1、Siphon 2、68L liquid storage bottle 3、bottle head valve 4、collecting tube 5、discharge tube 6、check valve
7、connecting tube 8、pneumatic control tube 9、frame
Technical Parameter:

Storage volume(L)	70
Agent type	CO²
Agent filling weight(Kg)	42
Density of the filled agent	≤0.60Kg/L
Storage pressure under 20°C (M pa)	5.7
Max. working pressure (M pa)	12.4
Discharge time(S)	≤60
Starting voltage / Current	DC24V/1.2A
Temperature range of storage room	0°C ~ +50°C
Humidity requirement of storage room	≤97%
Extinguishing way	Total or partial flooding
Starting delay time	0 ~ 30S adjustable
