50KW~90KW Marine diesel generator set

Date:2020-06-05  Click:584   Share to:

    • 50KW~90KW Marine diesel generator set

    Gensets Model
    BMMPPMGY50
    BMMPPMGY64
    BMMPPMGY75
    BMMPPMGY75
    BMMPPMGY90
    Rated Capacity(KVA)
    50/62.5
    64/80
    75/93.8
    75/93.8
    90/113
    Engine Diesel Model
    YC6108CA
    YC6108ZC
    YC6108ZC
    YC6108LCA
    YC6108LCB
    Rated power/Speed(KW/r/min)
    63/1500
    80/1500
    80/1500
    90/1500
    112/1500
    Type
    Vertical,inline,water-cooled,4 stroke
    Intake way
    Natural aspiration
    Turbo-cooled
    Turbo-cooled
    No. of Cylinder - bore*stroke
    6 - 108*125
    6 - 108*132
    Starting type
    Electric start
    Total displacement(L)
    6.871
    7.252
    Min.fuel consumption g/(KW.h)
    ≤198
    ≤197
    ≤195
    Oil capacity(L)
    16
    22
    Lw Noise limit
    ≤98
    Generator Lan Generator Model
    TZHW-50
    TZHW-64
    TZHW-75
    TZHW-75
    TZHW-90
    Rated voltage
    400
    400
    400
    400
    400
    Current(A)
    90.2
    115
    135
    135
    162
    Regulator approach
    AVR
    Freq.(Hz)
    50
    50
    50
    50
    50
    Power factor(CosΦ)
    0.8 lagging
    Phase
    3-phase
    Package Net Weight(kg)
    1580
    1500
    1530
    1560
    1630
    Packing size L*W*H(mm)
    1900*800*1100
    1960*800*1100
    1980*800*1200
    2000*820*1300
