100KW~120KW Marine diesel generator set

Date:2020-06-05  Click:355   Share to:

    • 100KW~120KW Marine diesel generator set

    Gensets Model
    BMMPPMGY100
    BMMPPMGY100
    BMMPPMGY120
    BMMPPMGY120
    Rated Capacity(KVA)
    100/125
    100/125
    120/150
    120/150
    Engine Diesel Model
    YC6108ZLCB
    YC6A170C
    YC6A170C
    YC6M195C
    Rated power/Speed(KW/r/min)
    112/1500
    125/1500
    125/1500
    143/1500
    Type
    Vertical,inline,water-cooled,4 stroke
    Intake way
    Turbo-cooled&inter-cooled
    No. of Cylinder - bore*stroke
    6 - 108*132
    6 - 108*132
    6 - 108*132
    6 - 120*145
    Starting type
    Electric start
    Total displacement(L)
    7.252
    7.252
    7.252
    9.839
    Min.fuel consumption g/(KW.h)
    ≤195
    ≤189
    Oil capacity(L)
    22
    22
    22
    34
    Lw Noise limit
    ≤98
    Generator Lan Generator Model
    TZHW-100
    TZHW-100
    TZHW-120
    TZHW-120
    Rated voltage
    400
    400
    400
    400
    Current(A)
    181
    181
    216
    216
    Regulator approach
    AVR
    Freq.(Hz)
    50
    50
    50
    50
    Power factor(CosΦ)
    0.8 lagging
    Phase
    3-phase
    Package Net Weight(kg)
    1680
    1730
    1760
    2600
    Packing size L*W*H(mm)
    2000*820*1300
    2500*960*1500
