Electric Outboard motor

Date:2020-06-04  Click:344   Share to:

  • Electric Outboard motor

    Specification:

    Model No.

    Thrust(Lbs)

    Voltage

    Max Current

    Installed Location

    Spead control

    Driving way

    Length of Shaft

    Rated speed

    Gross Weight



    Lbs (Kgf)

    (V)

    (A)







    CM

    R/MIN

    (KG)

    ET34

    34 (15)

    12

    32

         Poop

     5-sp-forward 2-sp-reverse

     Hand rudder/ Telescopic handle

    91

    1300

    10

    ET44

    44 (20)

    12

    42

    91

    1300

    11

    ET54

    54 (25)

    12

    50

    105

    1370

    12

    ET80

      80(36)

    24

    56

    137

    1400

    15

    Description:

    BOCHI Marine Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.
    Outboard motor is one of our main products, Including diesel outboard motor, gasoline outboard motor, Electric propulsion outboard motor and some small trolling motor. Power varied from 2 hp to 90 hp, and we also can supplied other famous brand outboard motor like Yamaha, suzuki and so on.

    Main Features:

    1.Main Shaft material is available with stainless steel and aluminum alloy to ensure Trolling Motor’s enough rigidly and durability.
    2.Abtains various speed modes, 5-speed forward and 2-speed reverse.
    3.Also abtains electronic speed mode.
    4.Available with telescopic handle and fixed handle.
    5.Outboard transom mounting is convenient to be quick installed, and with anti-impacting clip system to protect trolling motor.
    6.Anti-twist prop prevents clogging the prop during running.

    Details: These Trolling Motors are battery powered which are easy to operate and with the advantage of environmental protection. It is not noisy in the fishing zone and is the anglers’ very good helper.

    Boats equipped with Trolling Motor:
    ●Boat bears the weight of two people: Continuously traveling for 3 hours at the speed of 5 miles/hour, equipped with the batter of ( 12V, 60AH).
    ●Boat bears the weight of four people: Continuously traveling for 2 hours at the speed of 5 miles/hour, equipped with the batter of ( 12V, 60AH).
    ●Boat bears the weight of six people: Continuously traveling for 1.6 hours at the speed of 4.5 miles/hour, equipped with the batter of ( 12V, 60AH).

    As equipped with battey (you can buy battery with different capacity in local auto components stores), it won’t produce tremendous noise as a traditional motor does. It allows you to enter the fishing zone quietly without frientening away fishes.
    Its quality materials and beautiful flow line appearances makes it abtain the merits of stability and reliable performance.
    Uses can operate it with telescopic handle, the max length of telescopic scope is 15cm.
    The relevant parameters:
    The max Thrust: 1.5 HP 5-speed forward and 2-speed reverse. 12V х 60AH battery is recommended.
    Carton packaging: 126х55х19cm, about 0.1317 square meters (ET 54/44); 110 x 52 x 19cm, about 0.1087 square meters (ET 34)

    Pictures:
