Specification:
Model
|
YK10
|
Cylinder No. Bore x Stroke(mm)
|
1-86x70
|
Total Displacement(ml)
|
406
|
Max Output Power(KW/hp)
|
7．5/10
|
Engine Max Speed(r/min)
|
3800
|
Fuel consumption(g/KW.H)
|
≤280
|
Engine type
|
V-twin, 4-stroke, Air cooled, DI
|
Lubricating way
|
Forced Lubrication
|
Starting Way
|
Electric
|
Net weight(kg)
|
72
|
Crossbar Height(mm)
|
530
|
Total Length(mm)
|
870
|
Total Width(mm)
|
550
|
Total Height(mm)
|
1430
|
Engine Oil Capacity(L)
|
1.3
|
Description:
1.The outboard motor is fit for fiberglass boat, inflatable boat, aluminum boat and other sail boat,fishing boat.
2.CDI ignition system makes the outboard motor start easier
3. some parts for free with every motor
4.Long term reliability
5.Durable , High performance, reasonable fuel consumption , easy for service
6.Aircooled, 4 stroke, diesel engine, extremely low oil consumption
Air-cooled diesel Motor Fetures:
|
| Well adapted for whole day, safe and reliable |
| Good performance for continuation ability |
| Compaction design, low weight, small dimension |
| Easy to start, using convenient, simple maintenance |
| Save fuel: comparing to gasoline engine with the same power |
| The maximum fuel consumption is only 2-3L per hour |
| It saves more than 50% fuel |
| Environmentally friendly: engine emission targets passed |
Cetification: CE , ISO
Note: Please use it as the operating manual, especially if you never use a outboard motor before.
Any questions, you can conatct us for more details.
|
