2 Stroke 15HP L2 Manual Start Outboard Engines with Short Shaft

Date:2020-06-04  Click:318   Share to:

    • 2 Stroke 15HP L2 Manual Start Outboard Engines with Short Shaft

    Technology & Parameters:

    Model
    Unit
    BMMPP-OB 005S
    Overall Length
    mm(in.)
    870(33.4)
    Overall Width
    mm(in.)
    328(12.9)
    Overall Height
    mm(in.)
    1039(40.9)
    Transom Height
    mm(in.)
    381(15)
    Weight
    kg
    36
    Full Throttle Operating Range
    r/min
    4500-5500
    Max.Output
    kw(hp)@r/min
    11(15)@5000
    Idling Speed(Neutral)
    r/min
    700_800
    Engine Type
    		 　
    2 Stroke
    Cylinder
    		 　
    L2
    Displacement
    cc
    246
    Bore*Stroke(mm)
    		 　
    56*50(2.20*1.97)
    Ignition System
    mm(in.)
    CDI
    Control System
    		 　
    Tiller Control
    Starting System
    		 　
    Manual Start
    Gear Position
    		 　
    Forward-Neutral-Reverse
    Gear Ratio
    		 　
    2.08(27/13)
    Trim and Tilt System
    		 　
    Manual Tilt
    Fuel Tank Capacity
    L
    24
    Max. Fuel Consumption
    L/h
    7.9
    Engine Oil Capacity
    L
    (Fuel:Oil Ratio:50:1)
    Gear Oil Capacity
    cm3
    250
    Propeller Options
    in
    3-91/4*8" or 3-91/4*11"
    propeller choice will vary by boat size and application
    B=Back control F=Front control M=Manual start W=Electrical start S=Short Shaft L=Long Shaft




    Describtion:

    BOCHI Marine Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.

    Outboard motor is one of our main products, Including diesel outboard motor, gasoline outboard motor, Electric propulsion outboard motor and some small trolling motor. Power varied from 2 hp to 90 hp, and we also can supplied other famous brand outboard motor like Yamaha, suzuki and so on.

    1.The outboard motor is fit for fiberglass boat, inflatable boat, aluminum boat and other sail boat,fishing boat.

    2.CDI ignition system makes the outboard motor start easier

    3. some parts for free with every motor

    4.Long term reliability

    5.Durable , High performance, reasonable fuel consumption , easy for service

    Cetification: CE , ISO

    Note: Please use it as the operating manual, especially if you never use a outboard motor before.

    Any questions, you can conatct us for more details.
