Specification and Pictures:
Model
|
T40FW
|
H.P.
|
40HP
|
Shaft Length (mm/in) (S)
|
400/15.7
|
Shaft Length (mm/in) (L)
|
520/22
|
Engine Type
|
2 cylinders,2 stroke
|
Displacement (cm3)
|
489/516
|
Bore x Stroke (mm)
|
72x60/74x60
|
Max. Output (hp/kw)
|
25/18.4-40/29.4
|
RPM
|
4500～6000
|
Compression Ratio
|
6.5
|
Scavengine Method
|
Loop
|
Ignition System
|
CDI
|
Fuel Consumption Ratio(g/kwh)
|
490
|
Transmission Ratio
|
13/27
|
Steering
|
Front steering wheel
|
Lubrication
|
Premix
|
Starting system
|
Electric
|
Emergency Flameout Switch
|
√
|
Starting protection
|
√
|
Thermostatic Cooling System
|
√
|
Propeller(Standard)
|
10-1/2x11-10-1/2x13
|
Fuel Tank
|
23L
|
Tool Kit
|
√
|
Weight(S)
|
58-63
|
Weight(L)
|
61-65
|
Packed Case Size(mm)
|
1380*435*766
|
Container Loading
|
20 ft=63 sets, 40 ft=129 sets
|
Note: B=Back control, F=Front control, M=Manual start, W=Electrical Start, S=Short Shaft, L=Long shaft
Package: carton box with high quality foam& wooden carton as customer request
Sample available
ompany Information:
BOCHI Marine Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.
Outboard motor is one of our main products, Including diesel outboard motor, gasoline outboard motor, Electric propulsion outboard motor and some small trolling motor. Power varied from 2 hp to 90 hp, and we also can supplied other famous brand outboard motor like Yamaha, suzuki and so on.
Motor feature:
CD ignition makes starting easier and provides stronger power.
Unique gear-switching mechanism makes more stable.
Passed over 800 hours endurance intensifying experiment.
Dual water inlets, unique thermostat and thermal controller provide optimum cooling effect.
Enhanced corrosion resistance:
1.Multiplicate corrosion resistance technologies are used for long-term reliability.
2.Unique aluminum alloy and high-strength stainless steel.
3.Pre-treated painting process with high adhesion.
4.Multiple paint-coats with stronger protection.
5.Electrochemistry corrosion resistance technology.
6.Rubber impeller of special material.
7.The outboard motor is fit for fiberglass boat, inflatable boat, aluminum boat and other sail boat,fishing boat.
8. some parts for free with every motor
9.Long term reliability
10..Durable , High performance, reasonable fuel consumption , easy for service
Certification: CE , ISO
Note: Please use it as the operating manual, especially if you never use a outboard motor before.
Any questions, you can conatct us for more details.
|
