Diesel Engine
Specification:
Model
|
X2105BC-15
|
X2105BCF-15
|
X4105BC-15
|
X4105BC-20
|
X4105BCF-15
|
Max.Output(kw)
|
16.2/1500
|
16.2/1500
|
32.4/1500
|
39.7/2000
|
32.4/1500
|
Full Throttle Operating Range(rpm)
|
17.7/1545
|
17.7/1545
|
35.3/1545
|
43.7/2060
|
35.6/1500
|
Stroke
|
4
|
4
|
4
|
4
|
4
|
Cylinder
|
2
|
2
|
4
|
4
|
4
|
Displacement(cc)
|
2.078
|
2.078
|
4.156
|
4.156
|
4.156
|
Compression Ration
|
17
|
17
|
17
|
17
|
17
|
BorexStroke(mm
|
105*120
|
105*120
|
105*120
|
105*120
|
105*120
|
Cooling System
|
water-cooling
|
water-cooling
|
water-cooling
|
water-cooling
|
water-cooling
|
Starting System
|
electric
|
electric
|
electric
|
electric
|
electric
|
| FEATURES: |
|
|
1.Using direct injection combustion system, good startability,
low fuel consumption, low smoke, low emissions, low noise. |
2.Using fresh water, river water dual cycle cooling system,
water cooling system exhaust pipe, the air vessel are of good quality and low temperature. |
3.When using two split type cylinder head,
cylinder head saving the cost of the maintenance and use. |
4.Low and high strength of the body with tile window,
use maintenance and maintenance is very convenient |
5.Low electrical components with moistureproof,
mouldproof, special functions such as salt mist. |
|
|
