225KW Electric Start Diesel Engine

Date:2020-05-29  Click:233   Share to:

    •
    225KW Electric Start Diesel Engine





    Model

    HK6113ZLD

    Max.Output(kw)

    225

    Full Throttle Operating Range(rpm)

    ≤208g/kw.h

    Ignition syetem

    1-5-3-6-2-4

    Cylinder

    6

    Displacement(cc)

    7.518

    Compression Ration

    17:01

    BorexStroke(mm)

    125mm*113

    Starting System

    Electric start

    dimmension(L*W*H)

    2550*890*1420mm

    weight

    600KG

    Generator model

    150KW

     Generator rated Capacity

    187.5KVA

    Generator rated Output

    155

     Generator rated Voltage

    480V

     Generator rated Current

    270A




    sample avaiable



    FEATURES:
    1.Using direct injection combustion system, good startability,
    low fuel consumption, low smoke, low emissions, low noise.
    2.Using fresh water, river water dual cycle cooling system,
    water cooling system exhaust pipe, the air vessel are of good quality and low temperature.
    3.When using two split type cylinder head,
    cylinder head saving the cost of the maintenance and use.
    4.Low and high strength of the body with tile window,
    use maintenance and maintenance is very convenient
    5.Low electrical components with moistureproof,
    mouldproof, special functions such as salt mist.
