Main Data
|
Number of cylinder
|
|
5
|
Bore
|
mm
|
210
|
Stroke
|
mm
|
290
|
Compression ratio
|
|
13
|
Displacement/cylinder
|
L
|
10
|
Max. combustion pressure
|
MPa
|
13.5
|
Spec. fuel oil consumption
|
g/（kW·h）
|
202
|
Spec. lub oil consumption
|
g/（kW·h）
|
1
|
Height of lifting piston from crankshaft(D)
|
mm
|
1785
|
Overall dimensions（L×W×H）
|
mm
|
2970×1425×2230
|
Net weight
|
t
|
8.1
|
The main data of left engine is same with right engine in every model engine.
|
Rotation direction of crankshaft: The left engine resolves right, the right engine resolves right to look from the flywheel side to the free side, to turn right is clockwise.
|
The left engine resolves left, the right engine resolves left to look from the flywheel side to the free side, to turn left is counter-clockwise.
|
Starting method: Air motor or electric motor.
|
