Main Data
|
Number of cylinder
|
|
9
|
Bore
|
mm
|
250
|
Stroke
|
mm
|
320
|
Compression ratio
|
|
12.5
|
Displacement/cylinder
|
L
|
15.7
|
Max. combustion pressure
|
MPa
|
14
|
Spec. fuel oil consumption
|
g/（kW·h）
|
198
|
Spec. lub oil consumption
|
g/（kW·h）
|
1
|
Height of lifting piston from crankshaft(D)
|
mm
|
2010
|
Overall dimensions（L×W×H）
|
mm
|
5680×1500×2990
|
Net weight
|
t
|
15.5
|
The main data of left engine is same with right engine in every model engine.
|
Rotation direction of crankshaft: The left engine resolves right, the right engine resolves right to look from the flywheel side to the free side, to turn right is clockwise.
|
The left engine resolves left, the right engine resolves left to look from the flywheel side to the free side, to turn left is counter-clockwise.
|
Starting method: Air motor starting.
|
