Product No.
|
6N330-UN
|
6N330--SN
|
6N330-EN
|
8N330-UN
|
8N330--SN
|
8N330-EN
|
Type
|
in-line direct injection、exhaust turbocharged、4 stroke、Water cooling
|
Cylinder
|
6
|
8
|
Bore/Stroke (mm)
|
330/440
|
Rated Speed (r/min)
|
620
|
Continuous output (kW)
|
2207
|
2427
|
2574
|
2942
|
3163
|
3310
|
Mean Effective Pressure (Mpa)
|
1.892
|
2.081
|
2.206
|
1.892
|
2.081
|
2.206
|
Piston Average Speed (m/s)
|
9.09
|
Minimumsteady speedunder load(r/min)
|
248
|
Spec. Fuel Oil Consumption (g/kW.h)
|
190
|
Spec. Lub Oil Consumption (g/kW.h)
|
1.1
|
Fire sequence
|
1-2-4-6-5-3（clockwise）；1-3-5-6-4-2（counter-clockwise）
|
1-4-7-6-8-5-2-3（clockwise）：1-3-2-5-8-6-7-4（counter-clockwise）
|
Starting method
|
Compress air motor starting
|
Height of lifting position Crankshaft (mm)
|
3223（above thecenterline of crankshaft ）
|
Height of lifting cyclinder Crankshaft(mm)
|
3608（above thecenterline of crankshaft ）
|
Dimension （mm）
|
5248×1875×3627
|
6593×1890×3539
|
Net Weight （kg）
|
30000
|
43000
|
