Specification
RF Input: UHF:470MHz~862MHz
VHF:174MHz~230MHz
Input Impedance:75Ω
Signal Level:-80dBm~-10dBm
Connector Type: SMA type terminal×2
Channel Band Width: 6M/7M/8M
Constellation: QPSK, 16QAM, 64QAM
Guard Interval: 1/32, 1/16, 1/8, 1/4
FEC: 1/2, 2/3, 3/4, 5/6, 7/8
COFDM Carrier Mode: 2K And 8K Non Hierarchical/Hierarchical
Transport Stream: MPEG-4AVC/H.264 HP@L4
MPEG-2 MP@HL/ML
Video Aspect Ratio: 4:3/16:9
Video System: PAL/NTSC
Video Output: 1±0.3Vpp
Video Resolution YPbPr Resolution:
720*576@25fps/720*480@30fps/HD
1920×1080p/1920×1080i
Audio Decoder: MPEG-2/HE_AAC(DD/DD +optional)
Audio Channel: R/L/ST
Audio Output: 1Vpp 47Kohm Adjustable With E Volume
Power Cable And Jack: 4Pins:
1. DC+12~24V Input
2. ACC
3. GND
4.NC
IR Extension Jack: For IR Extension Box
A/V Output Jack: Video RCA Jack×1,Audiop RCA Jack(R/L) ×2
Upgrade and Multimedia Port: USB
S-AV connector :
Input Jack :Video RCA Jack×1, Audio RCA Jack (R/L)2
Ouput Jack: Video RCA Jack×2
ANT1,ANT2 Input Jack: Female SMA Type
Operating Temperatuer:-10℃~+50℃
Storage Temperatuer:-40℃~+65℃
Power Supply: DC+12V~24V±10%
Power Consumption: Running: 4.5W Max.
Standby: <0.85W.
Dimension: 25(H)*118(L)*78(W) mm
|
