6 Cylinder WD415 Series Turbo Marine Diesel Engine

WD415 class marine engine, the series products of WD615 marine engine, is introduction of the advanced European design concepts and therefore the upgraded keybasic components are more reliable.The frame balance mechanism with two shafts installed in the crankcase bottom,patented by the Chinese national authority,has thoroughly overcomed the problem of big vibrationin the four cylinder engines and it is designed to have the character of the six cylinder engines .when designed, it was fully taken into consideration to keep the main components ingeneral use in WD615 engines, such as the cylinder cover,the piston connecting rod mechanis,the valve mechanism,the gear driving system,the lubricating system,the cooling system,the gearbox,the flywheel,the flywheel case and most of the external assembly,except the lengthwise components like body,crankcase,intake and exhaust manifolds,camshaft ,crankshaft etc.The sales service is well distributed and it is easy to do the maintenance and repair.

Advantage:

More powerful with bigger torque reserve:the maximun power 240 horsepower,the maximum torque 950N.m and the torque reserve as much as 23.6%.
Outstanding performance and efficient:specially equipped with PS7100 injection pump,stop electromagnetinthe main engine,the electric governor in the anciliary engine，low fuel consumption at a wide power and engine speed range,the lowest fuel consumption rate with total power is less than 198g/kW.h.
The patented balance mechanism:it has thoroughly solved the problem of the secondary reciprocating inertia force particular to the four cylinder engine;there is no effect on the engine dimension and the original engine structure as the whole balance mechanism is set in the oil pan and it is convenient tp lay out inside the ship.
Widely fit for various engines:it is widely fit for various marine engines and generate set engines.
