High Speed Low Oil Consumption Pielstick Marine Diesel Engines

Date:2020-05-27  Click:231   Share to:

    • High Speed Low Oil Consumption Pielstick Marine Diesel Engines

    Diesel Engine Operating Zone

    Sketch of Pielstick Diesel Engine

                            Technology & Parameters:
    Engine Type
    BM-MPP-DE032
    BM-MPP-DE033
    BM-MPP-DE034
    BM-MPP-DE035
    Cyl. No.
    12
    16
    18
    20
    Maximal continuous rating power
    (kW)
    4860
    6480
    7290
    8100
    Dimensions(mm)
    A
    3055
    3975
    4435
    4895
    B
    5924
    6948
    7644
    7863
    C
    2460
    2460
    2714
    2714
    D*
    3391
    3391
    3620
    3620
    Dry mass (t)
    32.8
    40.1
    43
    46
    Cylinder bore
    280 mm
    Piston stroke
    330 mm
    Speed
    1,050 r/min
    Brake mean effective pressure
    2.28 Mpa
    Power per cylinder
    405 kW
    Specific fuel consumption
    197 g/kWh
    Lubricating oil consumption
    0.7 g/kWh
    Exhaust gas emissions Nox
    10.0 g/kWh

                             Note: D* is the engine height with wet oil sump.
